The main features of SS316 stainless steel pipe are:
Corrosion resistance: Contains molybdenum, which enhances corrosion resistance in chloride environments, especially seawater and salt-damaged areas.
High temperature resistance: It can be used for a long time in an environment up to 870 degrees Celsius, and short-term use of higher temperatures will not affect its characteristics.
Mechanical properties: It has good cold workability and weldability, and has excellent corrosion resistance.
Chemical composition: The main alloying elements include 16%-18% chromium, 10%-14% nickel and 2%-3% molybdenum.
Application areas: Widely used in chemical industry, aerospace, medical equipment, food processing and other industries
| Product Name | Stainless Steel Pipe/Tube |
| Standard | ASTM,JIS,DIN,GB,AISI,DIN,EN |
| Matériau | 201, 202, 301, 301L, 304, 304L, 316, 316L, 321, 310S, 904L, 410, 420J2, 430, 2205, 2507, 321H, 347, 347H, 403, 405, 409, 420, 430, 631, 904L, 305, 301L, 317, 317L, 309, 309S 310 |
| Technique | Etiré à froid, laminé à chaud, laminé à froid et autres. |
| Side shape | Round, square, rectangular,etc. |
| Outer Diameter | 20mm-1200mm or Customizable |
| Épaisseur | 6-3000mm or Customizable |
| Longueur | 1-12m or Customizable |
| Traitement de surface | BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D |
| Type | Seamless, Welded. |
| Origine | Chine |
| Code SH | 7304319000 |
| Délai de livraison | {Délai de livraison} |
| Service après-vente | 24 hours online. |
| Capacité de production | {Capacité de production} |
| Price Terms | EXW, FOB, CIF, CRF, CNF ou autres. |
| Port de chargement | {Port} |
| Section Shape | Round, Square, Rectangular, etc. |
| Délai de paiement | TT, LC, Cash, Paypal, DP, DA, Western Union ou autres. |
| Application | 1. Vaisselle, armoires, canalisations intérieures, chauffe-eau, chaudières, baignoires |
| 2. Pièces automobiles | |
| 3. équipements médicaux, matériaux de construction, produits chimiques, industrie alimentaire, agriculture, composants de navires, etc. | |
| Emballage | Emballage, sac en PVC, ceinture en nylon, serre-câble, emballage maritime standard pour l'exportation ou selon la demande. |
| Service de traitement | Pliage, soudage, décochage, poinçonnage, découpage et autres. |
| Tolérance | ±1% |
| MOQ | {MOQ} |
Composition de l'acier inoxydable
L'acier est un alliage de fer et de carbone. Les aciers inoxydables sont des aciers contenant au moins 10,5% de chrome, moins de 1,2% de carbone et d'autres éléments d'alliage. La résistance à la corrosion de l'acier inoxydable et
Les propriétés mécaniques peuvent être encore améliorées par l'ajout d'autres éléments, tels que le nickel, le molybdène, le titane, le niobium, le manganèse, etc.
| Grade | C | Si | Mn | P | S | Cr | Ni | Mo | N | Cu |
| 201 | ≤0.15 | ≤0.75 | 5.5~7.5 | ≤0.060 | ≤0.03 | 16.00~18.00 | 3.5~5.5 | – | – | 0.08 |
| 202 | ≤0.15 | ≤1.00 | 7.5~10.00 | ≤0.060 | ≤0.03 | 17.00~19.00 | 4.0~6.0 | – | ≤0.25 | |
| 301 | ≤0.15 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 16.00~18.00 | 6.00~8.00 | – | ||
| 302 | ≤0.15 | ≤1.00 | ≤2.00 | ≤0.035 | ≤0.03 | 17.00~19.00 | 8.00~10.00 | – | ||
| 304 | ≤0.07 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 18.00~20.00 | 8.00~10.50 | – | ||
| 304L | ≤0.030 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 18.00~20.00 | 9.00~13.00 | – | ||
| 310S | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 24.00~26.00 | 19.00~22.00 | – | ||
| 316 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 16.00~18.00 | 10.00~14.00 | 2.00~3.00 | ||
| 316L | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 16.00~18.00 | 12.00~15.00 | 2.00~3.00 | ||
| 321 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 17.00~19.00 | 9.00~13.00 | – | ||
| 430 | ≤0.12 | ≤0.75 | ≤1.00 | ≤0.040 | ≤0.03 | 16.00~18.00 | – | |||
| 2205 | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.030 | ≤0.015 | 22.00~23.00 | 4.5~6.5 | 2.5~3.5 | ||
| 2507 | ≤0.03 | ≤0.08 | ≤1.20 | ≤0.035 | ≤0.015 | 24.00~26.00 | 6.00~8.00 | 3.0~5.0 | ||
| 904L | ≤0.02 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.035 | 19.00~23.00 | 23.00~28.00 | 4.0~5.0 | 1.0~2.0 | |
| INCONEL028 | ≤0.03 | ≤1.00 | ≤2.50 | ≤0.030 | ≤0.030 | ≤28.0 | ≤34.0 | ≤4.0 | ≤1.4 | |
| MONEL400 | ≤0.30 | ≤0.5 | ≤2.00 | – | ≤0.024 | – | ≥63.0 | – | ≤34.0 | |
| INCONEL800 | ≤0.10 | ≤1.00 | ≤1.50 | – | ≤0.015 | ≤23.0 | ≤35 | 4.0~5.0 | – | ≤0.75 |
